150W UFO High Bay Light 130-150lm/w high output high bay light fixture workshop lighting warehouse lighting fixtures Acrylic lens or Aluminum reflector available ETL,cETL,CE,SAA (3HBA Series)
Description
Green Inova®‘s LED high bay is multifunctional. It can be used as UFO compact high bay which is easy for shipment and installation, or used with Aluminum reflector or Acrylic lens to create classic housing and more uniform lighting distribution with minimal glare. It is the energy efficient and maintenance free replacement or upgrade choice for existing HID metal halide and fluorescent high bay light fixtures.
The unique radial design with fins of durable cold forging Aluminum allow it to operate in -30˚C to 60˚C ambient environments and keeps the LEDs cool resulting in an estimated 100,000 hours of life at L70.
In addition, this fixture offers multiple options to meet any need – e.g. electrical controls, optics, mounting possibilities, and wire guard, etc.
Specification Summary
Typical Model | 3HBA150L40BK1 | 3HBA150L45BK1 | 3HBA150L50BK1 |
Power (W) | 150W | 150W | 150W |
Color Temperature (CCT) | 4000K | 4500K | 5000K |
Lumen Output (LM) | 19,707 | 19,707 | 19,707 |
Efficacy (lm/W) | 140 | 140 | 140 |
Input Voltage (V) | 100-277V (347-480V available) | ||
Power Factor | >90% | ||
THD | <20% | ||
CRI | ≥73 | ||
Optics | UFO, Clear Lens | ||
Beam Angle (°) | 120° | ||
IP Rate | IP65 Waterproof | ||
Reflectors | 60°/90°/120° Aluminum reflector, Acrylic lens optional | ||
Dimensions (in) | 10.23" Φ x 7.28" L | ||
LED Class | UL Listed: LM80 | ||
Driver Class | UL Listed: Class II | ||
Controls | Potocell / Dimming / Motion sensors available | ||
Environment | Indoor or outdoor | ||
Operating Temperature | –20°C to +50°C | ||
Certifications | ETL/cETL, LM79, LM80 | ||
L70 Lifetime (hours) | 150,000 hours per L70 TM-21@ 25°C | ||
Warranty | 6-year limited system warranty standard |
Features
Controls
• High system efficacy up to 140 LPW
• Excellent thermal management in one-piece structure by cold-forging technology
• LED TC<75°C (@ 25°C ambient)
• Internal and external radial thermal fins
• Unique designed UFO shape, lighter and smaller
• Aluminum reflectors and Acrylic lens available allowing for flexible designs
• Maintenance Free & Environmentally Friendly
• IP65 rated suitable for wet locations (*60W/320W only for indoor use)
• Wide mounting options for easy installation
• Various controls available allowing for further energy saving
• Reduces energy consumption ove 70%
Electrical
• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non–dimming/0-10V /DALI/Smart timer dimming
Housing & Finish
• Cold forging Aluminum housing
• Transparent dust proof cover
• Black (BK) standard , White (W) available on request
• RAL & custom colors available
• 0-10V dimming optional
• DALI dimming optional (*Only for 184W)
• Smart timer dimming optional (*Only for 184W)
• Photocell sensor optional
• Motion sensor optional
• Remote controller optional
Accessories Options
• Aluminum reflector
• Acrylic lens(PC cover)
• Wire guard
Compliance
• DLC listed
• ETL/cETL listed
• UL 1598 suitable for damp locations
• LM79, LM80 test reports
• CE & RoHS
• SAA
Ratings
• 150,000 hours per L70 TM-21@ 25°C
• Temperature Rated at –30°C to +60°C
Warranty
• 6-year limited system warranty
Optics Selection
• UFO: 120° and Type V (*Type V only for 320W)
• Aluminum reflector: 60°/90°/120° optional
• Acrylic lens: 70°
NOTE: 320W is NOT available to add reflectors*
Dimensions
Installation Options
1. Hook Mount (Std.)
2. Bracket Mount
3. Pipe Mount (Pipe is not offered)
Applications
• Exterior and Interior
• Industrial and Commercial
• Retail, gymnasiums, warehouses, manufacturing facilities, etc.
The 3HBA series is specifically designed for taller ceilings and larger areas. Ideal for use in warehouses, manufacturing plants, supermarkets, malls, retail stores, exhibition centers, arenas, stadiums, etc.
Project that feedback from our customer
Application: Gaston County Jail-Sally Port LED Lighting Upgrade
Location: North Carolina, USA
Result: Foot candle diff. increase 118.55
